Circuits | Dimensions (mm) | ||
DIM.A | DIM.B | DIM.C | |
02 | 0.8 | 1.9 | 3.9 |
03 | 1.6 | 2.7 | 4.7 |
04 | 2.4 | 3.5 | 5.5 |
05 | 3.2 | 4.3 | 6.3 |
06 | 4.0 | 5.1 | 7.1 |
07 | 4.8 | 5.9 | 7.9 |
08 | 5.6 | 6.7 | 8.7 |
09 | 6.4 | 7.5 | 9.5 |
10 | 7.2 | 8.3 | 10.3 |
11 | 8.0 | 9.1 | 11.1 |
12 | 8.8 | 9.9 | 11.9 |
13 | 9.6 | 10.7 | 12.7 |
14 | 10.4 | 11.5 | 13.5 |
15 | 11.2 | 12.3 | 14.3 |
16 | 12.0 | 13.1 | 15.1 |
17 | 12.8 | 13.9 | 15.9 |
18 | 13.6 | 14.7 | 16.7 |
19 | 14.4 | 15.5 | 17.5 |
20 | 15.2 | 16.3 | 18.3 |
