| Circuits | Dimensions (mm) | ||
| DIM.A | DIM.B | DIM.C | |
| 02 | 1.0 | 2.6 | 4.3 |
| 03 | 2.0 | 3.6 | 5.3 |
| 04 | 3.0 | 4.6 | 6.3 |
| 05 | 4.0 | 5.6 | 7.3 |
| 06 | 5.0 | 6.6 | 8.3 |
| 07 | 6.0 | 7.6 | 9.3 |
| 08 | 7.0 | 8.6 | 10.3 |
| 09 | 8.0 | 9.6 | 11.3 |
| 10 | 9.0 | 10.6 | 12.3 |
| 11 | 10.0 | 11.6 | 13.3 |
| 12 | 11.0 | 12.6 | 14.3 |
| 13 | 12.0 | 13.6 | 15.3 |
| 14 | 13.0 | 14.6 | 16.3 |
| 15 | 14.0 | 15.6 | 17.3 |
| 16 | 15.0 | 16.6 | 18.3 |
| 17 | 16.0 | 17.6 | 19.3 |
| 18 | 17.0 | 18.6 | 20.3 |
| 19 | 18.0 | 19.6 | 21.3 |
| 20 | 19.0 | 20.6 | 22.3 |
